Portable EV Charger 22kW 32A 3-Phase Type 2 – 5 Meters

Charge your electric vehicle quickly and safely at home or on the go with this portable Type 2 EV charger, delivering up to 22kW of charging power.

Designed for demanding EV owners, it supports 32A three-phase charging, features an informative display and offers adjustable charging current to match your vehicle and electrical installation.

Key Features

• Up to 22kW charging power
• 32A three-phase operation
• Type 2 vehicle connector (IEC 62196)
• Total cable length: 5 meters
• Adjustable current: 6A / 8A / 10A / 13A / 16A / 20A / 24A / 32A
• Easy-to-read display
• Memory function for preferred settings
• Fluorescent strip for improved night visibility

Safety Features

• AC 30mA + DC 6mA leakage protection
• Over-voltage protection
• Under-voltage protection
• Overload protection
• Over-temperature protection
• Lightning protection

Charging automatically stops if the internal temperature exceeds 85°C and resumes once safe operating temperatures are restored.

Technical Specifications

• Charging Mode: Mode 2
• Vehicle Connector: Type 2 (IEC 62196)
• Cable Length: 5 meters
• Rated Current: Up to 32A
• Output Power: Up to 22kW
• Operating Voltage: 380–450V AC (3-phase)
• Material: Thermoplastic and copper
• Insulation Resistance: >1000MΩ (DC500V)
• Housing Fire Rating: UL94V-0
• Origin: China
• Warranty: 2 years

Important: Achieving 22kW charging requires a compatible industrial red plug 32A three-phase electrical supply and an EV supporting 22kW AC charging.
